About Hanjiang

Hanjiang Heavy Industry Co., Ltd. is a subsidiary of China Railway 11th Bureau Group. It is dedicated to research, design, manufacturing, and servicing railway construction machineries.

Hanjiang is based in Xiangyang city, Hubei province. It is home to the ancient Xiangyang City Wall, one of the oldest still-intact city wall in China.

The company name was taken from the Han River (汉江 or Hàn Jiāng) that runs through the city. The Han Dynasty, one of the Chinese first golden ages, took its name from this river.

History

1959

Established as Repair Detachment of the First Division of Railway Corps.

1984

Transferred into the repair shop of 11th Engineering Bureau of the First Division of Railway Corps. Renamed into the Machinery Factory of China Railway Construction Corporation (CRCC) 11th Engineering Bureau.

2013

Hanjiang Heavy Industry Co., Ltd. was established as a specialized subsidiary of CRCC.

Engineering and Manufacturing Capacity

manufacturing bases across China.

4

400

sets of equipments produced per year.

217

million USD revenue per year.

45

National Patents.

Hanjiang main manufacturing base in Aerospace Industrial Park, Xiangyang City, Hubei Province.

Kunlun

Hanjiang TY-YT 1000/40, also known as "Kunlun", is the world's first 1000-ton class high-speed rail box girder erection machine. It was designed to transport and install 1000 tons and 40-meter long box girder. Kunlun fuselage has bolted connection design that can be customized to handle various girder length: 24 meters, 32 meters, and 40 meters.

Why is Kunlun a remarkable achievement in bridge construction engineering?

Firstly, it is the first machine that integrated box girder lifting, transportation, and placement functionalities into one unit. In the past, box girder erection needs two separate machines: One for lifting and lowering girder into position, another one for transporting girder from the stockyard to location. This integrated solution means Kunlun reduces the number of equipment needed and thus lowers the cost.

Secondly, Kunlun high lifting capacity enables bridge designers to use 40-meter long girder instead of the older 32-meter long one. Longer span means we need fewer bridge piers. This results in faster and lower construction cost for the piers.

Thirdly, because Kunlun integrates girder lifting and transportation, it cuts the time required to transfer the load from transporter to lifter. Kunlun takes only 2 hours to erect one bridge span. This is half hour faster than the previous system which takes 2.5 hours.

Hanjiang TY-YT 1000/40 Bridge Erection Machine "Kunlun" in Meizhou Bay cross-sea project.

Hanjiang "Kunlun" lowered the high-speed rail box girder in Meizhou Bay cross-sea project.

Award

In 2021, Hanjiang's Launching Gantry "Kunlun" was awarded the honorary title "10 Great Tools that Built the Nation" for its significant contribution in the construction of high-speed rail network in the People's Republic of China.

Hanjiang Indonesia

Hanjiang appointed PT Limov Power Structure (LIMOV) as their agent and strategic partner in Indonesia. LIMOV is Indonesian Engineering, Procurement, and Construction company that specializes in heavy lifting and moving.

Hanjiang and LIMOV adhere to the principle of “focusing on the long-term, complementary advantages, win-win cooperation and common development”.
